1 Step 1: Choose Compatible Dimmer
Step 1: Choose Compatible Dimmer
Match bulb type: LED dimmers for LED bulbs, CFL-compatible for CFL, standard for incandescent. Check wattage rating exceeds your total bulb wattage. Single-pole (one switch) or 3-way (two switches control one light).
2 Step 2: Turn Off Power
Step 2: Turn Off Power
Turn off circuit breaker for the switch. Use voltage tester on switch to confirm power is off. Test both terminals. Remove faceplate screws. Remove switch mounting screws.
3 Step 3: Identify and Label Wires
Step 3: Identify and Label Wires
Note wire connections before disconnecting. Usually: black (hot/line), black or red (load to light), white (neutral - may be capped in box), bare copper (ground). Take photo for reference.
4 Step 4: Disconnect Old Switch
Step 4: Disconnect Old Switch
Loosen terminal screws, remove wires. If wires are backstabbed (pushed into holes), insert small screwdriver in release slot while pulling wire. Unbend wires if hooked.
5 Step 5: Connect New Dimmer
Step 5: Connect New Dimmer
Strip 1/2" insulation if needed. Connect dimmer wires with wire nuts: black dimmer wire to hot (line), red or black dimmer wire to load, green to ground. Tuck wires carefully into box.
6 Step 6: Install and Test
Step 6: Install and Test
Screw dimmer into box (don't force - straighten if crooked). Attach faceplate. Turn power back on. Test switch - light should turn on/off and dim smoothly. Adjust trim if included for minimum brightness level.
